Maximum Takeoff Weight

8.8 oz / 249 g

Maximum Horizontal Speed

33.6 mph / 15 m/s

Maximum Ascent Speed

13.4 mph / 6 m/s

Flight Ceiling

2.5 Miles / 4000 m

Maximum Flight Time

28 Minutes

Maximum Hover Time

26 Minutes

Maximum Tilt Angle

33°

Hovering Accuracy

Vision Positioning
Horizontal: ±1.0' / 0.3 m
Vertical: ±0.3' / 0.1 m
GNSS
Horizontal: ±4.9' / 1.5 m
Vertical: ±1.6' / 0.5 m

Maximum Angular Velocity

200°/s (Pitch)

Sensor Type

1/1.28"-Type CMOS Sensor

Sensor Resolution

Effective: 50 Megapixel (8192 x 6144)

Focal Length

23mm (35mm Equivalent)

Field of View

85°

Maximum Aperture

f/1.9

Minimum Focus Distance

1.6' / 0.5 m

ISO Sensitivity

Photo/Video
100 to 6400

Shutter Speed

Electronic Shutter
1/8000 to 8 Seconds

Video Format

3840 x 2160p at 24/25/30 fps (100 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC)
2720 x 1528p at 24/25/30 fps (100 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC)
1920 x 1080p at 24/25/30/48/50/60 fps (100 Mb/s MOV/MP4 via H.264/AVC, H.265/HEVC)

Broadcast Resolution

None

Still Image Support

DNG / JPEG
50 MP (8192 x 6144)
12.5 MP (4096 x 3072)
(3840 x 2160)

Media/Memory Card Slot

Single Slot: microSD/microSDHC/microSDXC [256 GB Maximum]

Photo Modes

Auto-Exposure Bracketing (AEB), Burst Shooting, Interval, Single Shot

Number of Axes

3-Axis (Pitch (Tilt), Roll, Yaw (Pan))

Rotation Range

Mechanical Range
Pitch (Tilt): 160° (-125 to 35°)
Roll: 77° (-34 to 33°)
Yaw (Pan): 50° (-25 to 25°)
Controllable Range
Pitch (Tilt): 105° (-90 to 15°)

Follow Speed

Tilt: 30°/s

Stabilization Accuracy

±0.003°

GNSS Support

GPS, GLONASS, Galileo

Vision System

Downward / Forward / Backward

Vision System Capabilities

Forward
Measurement Range: 1.6 to 52.5' / 0.5 to 16 m
Max Speed: 32.8 ft/s / 10 m/s
Field of View: 40° (Horizontal) / 30° (Vertical)
Backward
Measurement Range: 1.6 to 59.1' / 0.5 to 18 m
Max Speed: 39.4 ft/s / 12 m/s
Field of View: 40° (Horizontal) / 30° (Vertical)
Downward
Measurement Range: 1.6 to 65.6' / 0.5 to 20 m
Hovering Range: 1.6 to 131.2' / 0.5 to 40 m
Field of View: 40° (Horizontal) / 30° (Vertical)

Operating Environment

Surface with Clear Patterns at >15 lux

Required Object Reflectivity

>20%

Operating Frequency

2.4 GHz (2.400 to 2.484)
5.8 GHz (5.725 to 5.850)

Maximum Operating Distance

6.2 Miles / 10.0 km

Transmitter Power

30 dBm (2.4 G)
30 dBm (5.8 G)

Transmitter I/O

1 x USB-C

Battery Capacity

3930 mAh

Mobile App Compatible

Yes: Android & iOS
App Name: Autel Sky
Functionality: Adjust Settings, Firmware Update, Remote Control, View Live Feed
*As of January, 2022: Check with manufacturer for the most up-to-date compatibility

Operating Temperature

32 to 104°F / 0 to 40°C

Battery Chemistry

Lithium-Ion Polymer (LiPo)

Battery Capacity

2250 mAh / 17.32 Wh

Battery Configuration

2 S / 7.7 V

Maximum Charging Power

30 W / 8.8 V

Charging Temperature

41 to 113°F / 5 to 45°C

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Output Voltage

5 V, 3 A
9 V, 3 A
12 V, 2.5 A

Power Rating

30 W

Rotor Configuration

4

Operating Temperature

22 to 72°F / -10 to 40°C

Diagonal Size

9.1" / 231 mm

Overall Dimensions

5.6 x 3.7 x 2.2" / 142.0 x 94.0 x 55.0 mm (Folded)
10.2 x 12.8 x 2.2" / 260.0 x 325.0 x 55.0 mm (Unfolded)

Package Weight

2.505 lb

Box Dimensions (LxWxH)

7.9 x 7.6 x 4.8"
